Mini CNC Router Small Machine
This small but sturdy mini CNC router machine boasts of an all-cast iron construction, ensuring a structurally stable, rigid and long-lasting performance. Its internal X, Y, Z three axes are equipped with professional ball screws and Taiwan Hiwin linear guides that ensure high precision and...
Description
This small but sturdy mini CNC router machine boasts of an all-cast iron construction, ensuring a structurally stable, rigid and long-lasting performance. Its internal X, Y, Z three axes are equipped with professional ball screws and Taiwan Hiwin linear guides that ensure high precision and reset accuracy, with a positioning accuracy that can reach 0.05mm. The machine is powered by a stepping system, providing a maximum speed of up to 4m~5.5m/min, while its high-speed water-cooled variable frequency motor delivers strong cutting force, large torque and high frequency.
Operated by a computer and a DSP handle control system with USB connection, this mini CNC router is incredibly easy to use and efficient. Its compact size makes it ideal for those with limited storage space, while its low cost and impressive features make it a popular choice among professionals and enthusiasts alike. Whether you're creating intricate designs or simply experimenting with new projects, this mini CNC router is guaranteed to deliver precision performance every time.
Technical Parameter | |
Model | Z3030 |
X,Y working area | 300×300mm |
Z Max working area | ＞100mm |
Table size | 350x350mm |
Working delicacy | 0.05mm |
X,Y,Z repositioning Positioning accuracy | 0.05mm |
Frame | Steel structure |
X,Y, Z Structure | Round orbit Ball screw (Y axis double nuts) |
Max.Speed | 4m~5.5m/min |
Spindle Power Motor | 1.5Kw water cooling spindle |
Power (not include the spindle) | 300w |
Spindle Speed | 0-24000RPM |
Drive Motors | Stepper system |
Working Voltage | AC220V/50Hz |
Command Language | G code |
Operating System | Computer control |
Running Environment | 。0°C45°C30％75％，： |
Surrounding for software | Windows98/2000/xp |
Packaging | Plywood |
Optional | Our control system utilizes a DSP handle and has a USB connection for communication. To convey the same meaning, we can reword it as follows: The control system we use is equipped with a DSP handle and facilitates USB connectivity. The Taiwan import Hiwin square orbit has been used to change the X, Y, and Z axis. A comparable statement can be formed by reordering the above statement to ensure that the content remains similar to the original text. It is important to note that the approach to generate the content must vary from the ChapGPT generated content. Change Y axis to square orbit Change to 2.2KW (220V) Flume |
Features
To ensure a stable structure and strong rigidity, the entire framework of the machine is made from cast iron.
2.Three axis all use profesional ball screw and linear guideways to ensure high accuracy and reposition precision.
To guarantee powerful cutting, high-frequency output, and a long lifespan, our machine incorporates a high-speed water-cooling variable frequency motor that delivers substantial torque.
Applications
Wood furniture industry | Doors; Cabinets; Tables; Chairs. From fine patterns to antique furniture, we offer a wide range of wooden furnishings including wave plates, screens, craft sashes, composite gates, cupboard doors, interior doors, sofa legs, and headboards. Each piece is carefully crafted and designed to add a touch of elegance to your living space. Our wooden doors are sturdy and stylish, ensuring that your home is both welcoming and secure. Whether you're in the market for a new sofa or just looking to update your home decor, we have the perfect piece for you. Choose from our selection of premium quality wave plates, fine patterns, and antique furniture to bring a touch of warmth and sophistication to your home. |
Advertising industry | Billboard; Signage; Display board; Meeting sign board; Badges; Logo. Advertising filed, sign making, acrylic engraving and cutting, crystal word making, blaster molding, and other advertising materials derivatives making. |
Die industry | A sculpture of copper, aluminum, iron and other metal molds, as well as artificial marble, sand , plastic sheeting, PVC pipe, and other non-metallic mold. |
Artwork and Decoration | wood crafts; gift box; jewelry box |
| Others | Relief sculpture and 3D engraving and Cylindrical object. |
