20w fiber laser marking machine
Looking to engrave on both metal and nonmetal materials with lightning-fast speed and high precision? Look no further than Zing's laser marking machine. With a speed of 7000mm/s and a resolution of 0.001mm, this machine can meet all of your marking needs. Contact us today to learn more! The...
Description
Looking to engrave on both metal and nonmetal materials with lightning-fast speed and high precision? Look no further than Zing's laser marking machine. With a speed of 7000mm/s and a resolution of 0.001mm, this machine can meet all of your marking needs. Contact us today to learn more!
The use features of laser marking equipment: |
The laser beam's quality is exceptional, making it ideal for applications requiring precision and fine marking.
The portability of the equipment is a key factor in adapting to frequently changing processing sites. With a small size and convenient carrying capabilities, it becomes a breeze to transport and set up the necessary tools. This portable solution enables maximum flexibility and allows for easy movement from one location to another without any hassle.
The equipment's high reliability ensures stable laser power output, guaranteeing consistent performance.
Let's talk about the introduction to equipment composition and configuration. This refers to the specific equipment selection and arrangement that is required for a particular task or function. In other words, it's about identifying the right equipment and making sure it's configured properly to achieve the desired results. This is an important step in any project or operation because it impacts the overall efficiency and effectiveness of the work being done. So, take the time to carefully consider the equipment composition and configuration before getting started and rest assured that this preparation will lead to success. |
The key components of a fiber-optic laser marking machine include the IPG fiber laser light, the scanning system comprising of the road and galvanometer, a computer control system, as well as the workbench. These elements work together to ensure precise and efficient marking of materials.
The optical fiber laser marking machine offers exceptional beam quality, allowing it to effectively satisfy the marking needs of various materials. Its beam quality ensures precision and accuracy when marking on different surfaces. Whether it is metal, plastic, or other materials, the optical fiber laser marking machine can deliver superior results. The machine's ability to maintain excellent beam quality guarantees optimal performance and reliable marking capabilities across a wide range of applications.
There are various materials that can be marked, such as metal, ceramic, PCB, coating plastic, and glass. It is important to consider the type of material before marking as different materials may require different marking techniques or machinery. For instance, marking on metal may involve laser engraving or dot peening, while marking on plastic may involve inkjet printing or laser marking. It is necessary to select the appropriate marking method for each material in order to achieve the desired outcome.
Life of the optical fiber laser: |
The optical fiber laser marking machine employs 915 nm laser diode as the source for pumping, which guarantees remarkable energy efficiency. Furthermore, this laser technology boasts excellent reliability with an average lifespan reaching up to 100000 hours.
In harsh environments, a compact and delicate device could be very useful. The device should have a small size but still be practical for usage. |
Optical fiber possesses exceptional softness and a compact, flexible design, making it an ideal choice for laser applications. Its small volume and high surface area-to-volume ratio contribute to efficient cooling, eliminating the need for large water cooling systems. Simple air cooling is sufficient, even in challenging conditions such as high impact, vibration, temperature variations, and exposure to dirt. This unique combination of qualities enables optical fiber to operate optimally in adverse environments.
Free maintenance operation: |
Optical fiber lasers are extremely low-maintenance devices, as they do not require any additional maintenance tasks apart from occasional lens adjustments and cleaning.
The metal laser marking machine features a technology parameter table that outlines its various specifications and capabilities. To create a highly similar content, the original information can be rearranged and presented in a structured manner. Here is an example: | |||
Technology index | Z30 | ||
Laser parameters | optical maser | WUHAN RAYCUS | |
Laser wavelength | 1064nm | ||
Average output power | 30W | ||
Whether or not to bring the light isolation | bring | ||
Modulation frequency range | 20kHz~80kHz | ||
Galvanometer parameters | Maximum speed | 7000mm/s | |
resolution | 0.001mm | ||
Repositioning precision | 0.003mm | ||
Optical output characteristics | Marking range | F = 160 mm, range 110 x 110 mm (with standard) | |
Minimum line width | 0.01mm | ||
inimum height of characters | 0.2mm | ||
Cooling system | Cooling way | Air cooling | |
System properties | Laser power supply | 0.5KW/AC220V/50Hz | |
Manual working table stroke | Movements itinerary 285 mm (desktop type) | ||
Environmental requirements | 0 ~ 35 ° C, 90% or humidity |
Samples of fiber laser marking machine: |
