Computerized CNC Plasma Metal Cutting Machine
The Computerized CNC plasma metal cutting machine utilizes advanced annular airflow technology to generate a slender and stable plasma arc, enabling it to effortlessly cut through conductive metals. Its superiority over traditional manual and semi-automatic cutting methods lies in its ability to...
Description
The Computerized CNC plasma metal cutting machine utilizes advanced annular airflow technology to generate a slender and stable plasma arc, enabling it to effortlessly cut through conductive metals. Its superiority over traditional manual and semi-automatic cutting methods lies in its ability to precisely control and enhance cutting quality and efficiency. Consequently, this machine leads to reduced labor costs and increased economic gains. With its user-friendly interface, exceptional precision, and accelerated work rate, the Computerized CNC plasma metal cutting machine finds extensive application in various workpiece processing tasks. Industries such as chemical machinery, automotive, and general construction machinery frequently employ this versatile cutting tool.
Part one: Main Technical Parameters | ||
Equipment | Specification | |
Model | Z1313 | |
Effective area | 1300*1300mm | |
Max running speed | 9000mm/min | |
Running precision | ±0.4mm | |
Re-position decision | ±0.2mm | |
Cutting capacity | Depend on the plasma power source | |
Drive mode | Middle drive | |
Cutting torch number | 1 plasma | |
Part two: Essential Equipment | |
Equipment | Brand or origin |
Control system | Start-DSP Shaphon China |
Auto height control | XPTHC, China (100mm) |
X, Y drive | Hybrid servo driver and motor |
X, Y transmission | Taiwan import square |
Software | Fast CAM |
Flume | stainless steel flume |
Guard bar | Red pointer protect |
Part three: Separation Quotation | |||
Parts | Equipment | Quantity | |
Control system | Control unit | 1 set | Start-DSP Shaphon China |
Accessories | 1 case | ||
Software | Programing Software | 1 set | Fast CAM（str） |
Servo system | X axis motor | 1 set | Hybrid servo motor and driver |
Y axis motor | 1 set | ||
Transformer | 1 set | ||
Mechanic Part | Host | 1 set | |
Linear tracks | 1 set | ||
Ball screw | 1 set | ||
Tackles | 1 set | ||
Towlines | 1 set | ||
Protective parts | 1 set | ||
Spray-print and other treatment | |||
Control cabinet | |||
Details Introduction |
Samples of plasma cnc cutter: |
