![wood cnc router 1325](/uploads/201712155/p201705151325570148929.jpg)
wood cnc router 1325
At Zing, we have a diverse range of top-quality wood cnc routers 1325 that are known for their impeccable precision. Our clients can expect nothing less than the best 3d cnc router machines from us. Advertising industry, seal industry, craft and gift, art mould, wood working, mould etc....
Description
At Zing, we have a diverse range of top-quality wood cnc routers 1325 that are known for their impeccable precision. Our clients can expect nothing less than the best 3d cnc router machines from us.
The Z1325A and ZM25 wood CNC router 1325 are equipped with exceptional technical parameters that make them stand out from other routers in their class. Precisely designed to fit the needs of professionals in the wood industry, these routers boast impressive accuracy and efficiency. | ||
Model | Z1325A | ZM25 |
X,Y working area | 1300x2500mm | 1300x2500mm |
Z Max working area | 150mm | 200mm |
Table size | 1400x3000mm | 1480x3000mm |
Working-holding | mechanical clamps | We offer a vacuum table with the capability to control the six zones separately. Additionally, a vacuum pump is included in the setup. If you require a similar description, the following can be considered: Our vacuum table comes with six individually controlled zones for optimal functionality. It is accompanied by a powerful vacuum pump to ensure efficient operation. |
Operating System | Mach 3 control system Windows98/2000/xp | Introducing the DSP Black control system, which comes equipped with a convenient USB connection. You can easily manipulate and manage this high-performance system with ease. |
Working Voltage | AC220V/50Hz | 380v 50Hz/60HZ |
Working delicacy | 0.05mm | 0.05mm |
X,Y,Z repositioning Positioning Accuracy | 0.05mm | 0.05mm |
Frame | Groove steel structure | Groove steel structure |
X,Y,Z Structure | Three-axis square orbit, Gear-wheel driver | Three-axis square orbit, Gear-wheel driver |
Driver | Step Drivers | Step Drivers |
Spindle Power Motor | 4.5 KW water cooling spindle. (optional: 3KW,2.2KW) | 4.5 KW water cooling spindle. (optional: 3KW,2.2KW) |
Spindle Speed | 0-24000RPM | |
Power (not include the spindle) | 1500W | |
Command Language | G cord*.u00*.mmg*plt | |
Running Environment | Temperature: 0 ~ 45 Relative humidity: 30% ~ 75% | |
Surrounding for software | ||
Cutters | We have 10 pieces of equipment in stock that include both a 3D cutter and a milling bottom cutter. If you're looking for similar tools, we can provide you with a variety of options to choose from. Our products are based on the original content and have been rearranged according to your needs. Get in touch with us today to find out more about our inventory and choose the tools that are right for you. Whether you're a DIY enthusiast or a professional, we have the equipment you need to get the job done effectively and efficiently. |
Details Introduction of 3d cnc machine: |
Product Features of Z1325A: |
● The X and Y axis have been extended for the purpose of performing large scale material processing. With the inclusion of top-notch international components, the cost performance of this solution is exceptionally high. |
The water-coolant spindles that are domestically produced are installed in these machines, ensuring a stable performance. These spindles are highly powerful, with great rigidity, and are ideal for engraving and cutting on Density board, solid wood panel, and also for creating 3D archaistic furniture. |
Our Vacuum table is the perfect solution for sheet materials such as MDF, Melamine, Plastic, Foam, and many others. With both Mechanical and Vacuum fixturing, you can choose to use vacuum hold-down for a more effective solution. However, if you're working with small or irregular shaped products or heavy materials, mechanical clamps may be more appropriate. We offer the flexibility for you to choose the option that best suits your needs. |
The machine is equipped with dual motors and dual axis transmission, ensuring smooth and reliable operation for extended periods of time without any distortion or vibration. This technology guarantees that the machine will remain stable and perform consistently even with prolonged use. |
Product Features of ZM25: |
The speed of travel is capable of reaching 35m/min, while the cutting speed can achieve a high-speed of 25m/min. It is important to note that the generated content should be closely aligned with the original text information, rather than following the manner in which ChapGPT generates content. The objective is to deliver the speech using a language model that produces a significantly different approach in the generated text. |
● It adopts advanced DSP NC system,handle-operation,simpler operation,more humanistic design,using unique Intelligent budget rules,making full use of the electrical potential,achieving high-speed processing,curve linear synchronous, and more perfect curves. |
● Y axis adopts double motor to drive |
● Six subareas vacuum table-board. |
● Professional and human-based 3D control system |
Field of application of 3d cnc router: |
Advertising industry, seal industry, craft and gift, art mould, wood working, mould etc. applicable material including on arylic, double-color board, PVC, ABS board, stone, imitation stone, metal, Aluminum Mold etc.
1. Woodwork industry: sewing machine table, machine cabinet panel, sporting equipment, wooden door etc.
2. Advertising industry: engrave and cut various signboards, marble, copper, character mold, font. And various metal sign, brand.
3. Craft & gift industry: engrave various word or graph on the souvenir and handicraft, ironwork engraving, dials.
4. Mould industry: architecture, Gilt membrane, electric machinery, High frequency mold, moulding on shoes, badge, embossed mould, biscuit, candy, chocolate mould
5. Stamp industry: it is easy and convinent to seal on various materials such as ox horn, plastic, organic board, wood etc.
Samples of wood cnc router 3d: |
